LAQUA EC2000-S :: Benchtop Conductivity/Resistivity/Salinity/Total Dissolved Solids/Temperature Meter

THE Kit Includes:

• * EC-2000 Meter
• * 9382-100 Conductivity Electrode
• * 84µS Conductivity standard, 250 ml
• *1413µS Conductivity standard, 250ml
• * 12.88mS Conductivity standard, 250ml each
• * Electrode Stand

Model    LAQUA-EC2000
Conductivity/Resistivity/TDS/Salinity/Temperature (°C/°F) Bench Meter
Conductivity Range    0.000 to 1.999 µS/cm (k = 0.1)
2.00 to 19.99 µS/cm (k = 0.1, 1)
20.0 to 199.9 µS/cm (k = 0.1, 1, 10)
200 to 1999 µS/cm (k = 0.1, 1, 10)
2.00 to 19.99 mS/cm (k = 0.1, 1, 10)
20.0 to 199.9 mS/cm (k = 1, 10)
0.200 to 2.000 S/cm (k = 10)
Units    Auto ranging S/cm, S/m (µS ↔ mS ↔ S)
Resolution    0.05% full scale
Accuracy    ± 0.6% full scale; ± 1.5% full scale > 18.0 mS/cm
Reference Temperature    15.0 to 30.0 °C (adjustable)
Temperature Coefficient    0.00 to 10.00 % per °C (adjustable)
Cell Constants    0.070 to 13.00 (adjustable)
Calibration Points    Up to 4 (Auto) / Up to 5 (Manual)
Resistivity Range    0.001 MΩ・cm to 20.0 MΩ・cm
Resolution    0.5% full scale
Accuracy    ± 0.6% full scale; ± 1.5% full scale > 1.80 MΩ・cm
Total Dissolved Solids (TDS) Range    0.01 to 9.99 mg/L (ppm)
10.0 to 99.9 mg/L (ppm)
100 to 999 mg/L (ppm)
1.00 to 9.99 g/L (ppt)
10.0 to 100 g/L (ppt)
Resolution    0.01, 0.1, 1 mg/L ↔ g/L (ppm ↔ ppt)
Accuracy    ± 0.1% full scale
TDS Curves    EN27888, 442, NaCl, Linear (0.40 to 1.00)
Salinity Range    0.0 to 100.0 ppt / 0.00 to 10.00 %
Resolution    0.1 ppt / 0.01%
Accuracy    ± 0.2% full scale
Salinity Curves    NaCl / Seawater
Calibration Option    Yes (Manual; 1 point)
Temperature Range    -30.0 to 130.0 °C / -22.0 to 266.0 °F
Resolution    0.1 °C / °F
Accuracy    ± 0.5 °C / ± 0.9 °F
Calibration Option    Yes (± 10.0 °C / ± 18.0 °F range in 0.1 °C increments)
Memory    2000
Auto Data Log    Yes
Real-time Clock    Yes
Date & Time Stamp    Yes
Measurement Modes    Auto Stable / Auto Hold / Real Time
Auto Shut-Off     Yes (Programmable: up to 30 mins.)
Electrode Status    On screen display
Diagnostics    Yes
Password Setting    Yes
Software Upgrade    Yes
PC / Printer Communication    Phono jack (USB / RS232C)
Meter Inputs    BNC, phono, DC sockets
Display    5" Custom LCD with backlight and 320 segments
Power Requirement    AC adaptor 100 - 240V, 50 - 60Hz
Dimensions & Weight    155(L) x 150(W) x 67(H) mm, 765g
