MA 50.R :: Moisture Analyzer

Functions :

*Drying modes

*Samples drying

*Moisture content
analysis

*Dry mass determination

Metrological parameters :

Maximum capacity [Max] :  50 g
Readability [d] : 1 mg
Tare range :  -50 g
Adjustment :  external
Maximum sample weight :  50 g
Heating module :  IR emitter
Moisture content repeatability : +/-0,05% (sample ~ 2g), +/-0,01% (sample ~ 10g)
Moisture content readability  :  0,001%
Drying temperature range : max 160 °C

Physical parameters
Levelling system manual
Display LCD (backlit)
Weighing pan dimensions ø90, h= 8 mm
Packaging dimensions 470×380×336 mm
Net weight 4,8 kg
Gross weight 6,3 kg
Protection class IP 43
Maximum sample height 20 mm
Communication interface
Communication interface RS232¹, USB-A, USB-B, Wi-Fi
Electrical parameters
Power supply 100-240 V AC 50/60 Hz
Power consumption 4 W
Heating module power 450 W
Environmental conditions
Operating temperature +10 ÷ +40 °C
