PTH 092 :: Compact Turbimeter

Turbidity and Total Suspended Solids (TSS) are two of the most important indicator parameters for water quality monitoring. The Compact Turbimeter provides the ideal testing platform using unique QuadoptiX™ technology with a sophisticated yet simple to use instrument.

The Compact Turbimeter provides:

• Maximum reliability and accuracy in the field - the QuadoptiX™ system offers four independent measurement points systems in a waterproof portable instrument
• Variety of operating/reading modes including Total Suspended Solids, averaging and continuous capture to measure all types of samples effectively
• Comprehensive hard case kit including instrument, calibration standards, sample cuvettes and other accessories.

Add to the physical product the sophistication of data log for results and a record of calibration data for GLP and the Compact Turbimeter is a key component in any water monitoring package.

True ISO7027 Compliance
Both Nephelometric turbidity measurement and compensated measurement for higher turbidity values, the Compact Turbimeter is truly compliant with the international standard.

Wide Measurement Range
Offering a turbidity range from 0 – 1050 NTU, the Compact Turbimeter is supplied with a dilution tube for samples with even higher levels of turbidity.

Reliable Measurement in all Samples
The QuadoptiX™ system operates as four independent turbidity measurements – two at 90° and two at 180°. Using all measurements allows any sample variation, cuvette contamination and optical fouling to be removed from the measurement system – a unique approach in a portable instrument.

Total Suspended Solids Measurement
Relating turbidity to a weight of suspended solids is a simple operation of correlating gravimetric results to turbidity values recorded in the instrument. Once correlation is established, simply choose the TSS mode and read samples as mg/l Suspended Solids.

Waterproof and Battery Powered
Built to withstand immersion to IP67 specification, and with an exceptionally low power consumption, the Compact Turbimeter is an ideal field instrument.

User and Sample ID Control
Multiple-user IDs and Sample IDs can be tagged to results and recorded in the result and calibration log. The Sample ID allows site specification correlation to be created for individual sample points.
