VAP 500 : Automatic distillation system

C. Gerhardt presents the new top-of-the-range model of the world’s most successful VAPODEST distillation systems. VAPODEST
distillation units are the first choice for laboratories looking for safe, reliable and flexible equipment that provides interactive
guidance for analyses and guidelines and fulfils the most stringent data management requirements. Provides standard-compliant
results in accordance with DIN EN ISO, AOAC, EPA, ASTM, EU Directives, APHA, etc.

TECHNICAL INFORMATION Details VAP 500
Integrated titration :Yes
Gerhardt Dashboard, program for data management : Yes
Variable steam power:  0–100%
Display size of touch display: 7", resolution 480x800 pixel
Resource-saving stand-by mode : Yes
Distillation time / sample:  2–4 min.
Recovery:  > 99.5%
Repeatability: ± 1%
Detection limit : 0.1 mg N absolute
Automatic addition of H3BO3, H2O, NaOH : Yes
Automatic extraction of samples/receivers : Yes
100, 250, 400, 800 and 1,200 ml digestion tubes possible : Yes
250 ml, 500 ml and 750 ml Kjeldahl flasks possible : Yes
Connection for fill level monitoring of set of tanks : Yes
Fill level monitoring of tanks : Optional/standard VAP 500C
Cooling water pressure : 1–6 bar
Nominal voltage* : 230 V, 50/60 Hz
Power consumption : 2,200 W/2,300 W
Weight approx. :  44 kg/205 kg
Dimensions VAP 500 (W x D x H) : 527 x 390 x 697 mm
Predefined methods : Yes
Customer defined methods : Yes
Pump calibration : Yes
